Request Information
Unit of Measure

Specifications

Brand

 N/A Klein®

Type

 N/A Lockout with Interlocking Tab

UPC Code

 N/A 92644452017

UNSPSC code

 N/A 39121901

Weight

 N/A 113 g3.99 oz

Material

 N/A Tempered Steel

Hasp Finish

 N/A Bright Zinc Plated

NEMA Color

 N/A Red

Locking Holes

 N/A 6 Coated in Red Vinyl Plastic

Dimensions

Closed Hasp I.D.

 N/A 1-1/2 in38.1 mm

Overall Length

 N/A 8 in203.2 mm

Overall Width

 N/A 1-1/2 in38.1 mm

Overall Height

 N/A 1/2 in12.7 mm

Application

Application

 N/A Specifically Designed for Locking Out Power Sources such as Disconnects, Switches, and Panel Boxes

Features

Features

 N/A
  • "Specifically designed for locking out power sources such as disconnects, switches, and panel boxes."
  • Double interlocking hasp of tempered steel with patented interlocking tabs for extra security.
  • Riveted construction.
  • Six-hole locking bodies coated with red vinyl plastic.
  • Holes will accept up to 5/16'' (8 mm) diameter shackles.
  • Use only in accordance with OSHA requirements.
