"Klein® Tools Electrician's Insulated High-Leverage Diagonal-Cutting pliers are 1000 V rated and VDE certified for safety on the job. The multi-color, sleek design with small thumb guards make for easy handling and storage. The three-part insulation with white under layer provides a warning sign that insulation may be compromised. The durable, molded insulation meets or exceeds IEC 60900 and ASTM F1505 standards for insulated tools."
Unit of Measure

Specifications

Brand

 N/A Klein®

Type

 N/A High-Leverage Insulated Diagonal Cutting Plier

UPC Code

 N/A 92644720079

UNSPSC code

 N/A 27112135

Handle Type

 N/A Slim

Handle Color

 N/A Orange, Gray

Cut Style

 N/A Diagonal-Cutting

Handle Finish

 N/A 3-Layer

Insulated

 N/A Yes

Cutting Knives

 N/A Standard

Joint Type

 N/A Hot Riveted

Nose Type

 N/A Tapered

Rated Voltage

 N/A 1000 V

Material

 N/A Induction Hardened Steel

Standard

 N/A International Electrotechnical Commission (IEC) 60900 and American Society for Testing and Materials (ASTM) F1505

Weight

 N/A 0.32 kg0.71 lb

Dimensions

Jaw Width

 N/A 1-3/16 in30.2 mm

Overall Length

 N/A 8-1/4 in209.6 mm

Jaw Thickness

 N/A 13/16 in20.6 mm

Jaw Length

 N/A 13/16 in20.6 mm

Handle Length

 N/A 6-3/4 in171.5 mm

Application

Application

 N/A Cuts ACSR, Screws, Nails, and Most Hardened Wire

Features

Features

 N/A
  • 1000 V Rated for safety on the job. VDE Certified
  • Unique three-part insulation with white under layer provides a warning sign that insulation may be compromised
  • "Multi-color, sleek design with small thumb guards for ease of handling and easy storage in your tool belt"
  • Induction hardened cutting knives for long life
  • Hot-riveted joint for smooth action and no handle wobble
  • "Durable, molded insulation meets or exceeds ASTM F1505 and IEC 60900 standards for insulated tools"
  • "Whenever possible, always de-energize lines and equipment prior to working on or around them. Klein® insulated tools are designed only to reduce the chance of injury where the tool may make contact with an energized source."
  • "Only use tools that are marked with the official international 1000-volt rating symbol shown below, if there is any chance that the tools will make contact with an energized source."
  • Always inspect your tools before use.
  • Do NOT touch uninsulated portion of the tool or any conductive object when either might contact an energized source.
  • "Keep tool clean, dry and free of any surface contaminants."
  • Destroy tool if the insulation is damaged in any way.
